Standard Features
| MACHINE MODEL | SVTS-650-S |
| Machine Dimension(LxWxH) | 1900 x 850 x 1750 |
| No.of Trays Can Feed At a Time | 1 to 6-depend upon tray/Cup size |
| Down Chamber Height | 75mm/ Can Be Customized As Per Requirment |
| Max Diameter Of Film Roll | 220 mm Diameter |
| Control Panel | POWERVAC Touch Screen HMI PLC |
| Electric Supply | 8 KW |
| Cycle Per Minute [with Map/only Seal] | 2 to 3 Cycles / 900 Tray of 250 gm & 600 Tray of 500 gm Tray Can Be Pack Per Hour |
| Vacuum Pump | Busch-Germany |
| Operation On Trays | Vacuum + Gas+ Sealing Cutting & Only Sealing-cutting |
| Machine Construction | Stainless Steel And Anodised Aluminium |
| Machine Weight | 600 Kg. |
| Voltage | 230V-1PH-50Hz |
Standard Features
Can Be Customized For The Different Tray Of Cup Size.
Air Compressor Required For Sealing Operation.
Can Change The Mould For Different Trays.
Optional Eye Mark Sensor For Printed Rolls.
Application
Sweets
Bakery Items
Sandwich
Meal
Snacks
Vegetables
POWERVAC group has gained prominence as India’s leading manufacturer of Chamber Type Vacuum Packaging Machinery.
