| MACHINE MODEL | SVTS-550R |
| Machine Dimension(LXWXH) | 1000x1155x1415 |
| No.of Trays Can Feed At a Time | 1 to 4-depend upon tray/Cup size |
| Down Chamber Height | 75mm/ Can Be Customized As Per Requirment |
| Max Diameter Of Film Roll | 220 mm Diameter |
| Control Panel | POWERVAC Touch Screen HMI PLC |
| Electric Supply | 4 KW |
| Vacuum Pump | 40 M/h(BUSCH) |
| Cycle Per Minute [with Map/only Seal] | 4/7 |
| Operation On Trays | Vacuum+ Gas+ Sealing Cutting & Only Sealing-cutting |
| Machine Construction | Stainless Steel And Anodised Aluminium |
| Machine Weight | 350KG |
| Voltage | 440V-3PH/50Hz |
Standard Features
Semi Auto But Shuttle Type Map Tray Selling Machine To Save Time For Trays LoadingUn-loading, Suitable Pre-made Trays And Cups.
Product Can Be Pack Like Sweets, Dry-fruits, Cakes, Ready Eat Foods, Frozen Food, Etc.
Accurate Vacuum-gas Flushing Systems.
Easy Mould Changing & Stainless Steel Body, No Sharps Edges, Use Cast Aluminum & Other Nonferrous Materials To Safe Rust Issue And Easy Cleaning.
Optional Features
Eye Mark Sensor For Printed Roll.
Can Be Customized According To Application.
Buffer Gas Tank.
